60% $470.40
UNV - IPC6315LFW-AX5C-VG1 - UNV 5MP Active Deterrence Plastic PTZ Camera (2.7mm-13.5mm,Audio&Alarm, Two-Way Audio, Starlight, Auto Tracking)
UNV - IPC6315LFW-AX5C-VG1 - UNV 5MP Active Deterrence Plastic PTZ Camera (2.7mm-13.5mm,Audio&Alarm, Two-Way Audio, Starlight, Auto Tracking)
UNV - IPC6315LFW-AX5C-VG1 - UNV 5MP Active Deterrence Plastic PTZ Camera (2.7mm-13.5mm,Audio&Alarm, Two-Way Audio, Starlight, Auto Tracking)
UNV - IPC6315LFW-AX5C-VG1 - UNV 5MP Active Deterrence Plastic PTZ Camera (2.7mm-13.5mm,Audio&Alarm, Two-Way Audio, Starlight, Auto Tracking)
UNV - IPC6315LFW-AX5C-VG1 - UNV 5MP Active Deterrence Plastic PTZ Camera (2.7mm-13.5mm,Audio&Alarm, Two-Way Audio, Starlight, Auto Tracking)
UNV - IPC6315LFW-AX5C-VG1 - UNV 5MP Active Deterrence Plastic PTZ Camera (2.7mm-13.5mm,Audio&Alarm, Two-Way Audio, Starlight, Auto Tracking)
Uniview

Uniview - IPC6315LFW-AX5C-VG1 - Uniview 5MP Active Deterrence Plastic PTZ Camera (2.7mm-13.5mm,Audio&Alarm, Two-Way Audio, Starlight, Auto Tracking)

Product SKU: IPC6315LFW-AX5C-VG1
Available:
Only 1000 items in stock
1000 items in stock
In stock
Pre-order
Out of stock
$318.60
$789.00
  • Description
  • Specifications
  • Downloads

5MP Active Deterrence Plastic PTZ Camera (2.7mm-13.5mm, Audio & Alarm, Two-Way Audio, Starlight, Auto Tracking)



Features:

  • High quality image with 5MP, 1/2.8" CMOS sensor
  • Ultra 265, H.265, H.264, MJPEG
  • Smart intrusion prevention, support false alarm filtering, include Cross Line, Intrusion, Enter Area, Leave Area detectio
  • LightHunter technology ensures ultra-high image quality in low illumination environment
  • Up to 120 dB WDR (Wide Dynamic Range)
  • Built-in Mic & Speaker
  • Smart IR, Up to 50 m (164 ft) IR distance and 15m (49 ft) warm light distance
  • Micro SD, up to 512GB
  • IP66 protection
  • DC12V or PoE (IEEE 802.3at) power supply
IPC6315LFW-AX5C-VG1
Camera
Max Resolution5MP
Sensor1/2.7" CMOS
Min. IlluminationColour:0.005lux (F1.6,AGC ON)
0 lux with IR
Day/NightIR-cut filter with auto switch (ICR)
ShutterAuto/Manual,
1 ~ 1/100000s
WDR120dB
S/N>56dB
Lens
Focal Length2.7 ~ 13.5 mm
Optical Zoom5X
IrisF1.6
Field of View (H)106.91°~33.55°
Field of View (V)56.45°~18.99°
Field of View (D)123.1°~42.1°
DORI
DORI Distance (Detect)72 m ~ 229.5 m (236.2 ft ~ 753 ft)
DORI Distance (Observe)28.8 m ~ 91.8 m (94.5 ft ~ 301.2 ft)
DORI Distance (Recognize)14.4 m ~ 45.9 m (47.2 ft ~ 150.6 ft)
DORI Distance (Identify)7.2 m ~ 23 m (23.6 ft ~ 75.3 ft)
Illuminator
Illumination Distance (Warm Light)15 m (49.3 ft)
Illumination Distance (IR)50 m (164.0 ft)
Wavelength850 nm
Light On/Off ControlAuto/Manual
Video
Privacy MaskUp to 4 areas
Video CompressionUltra 265, H.265, H.264, MJPEG
Frame RateMain Stream: 5MP (2880*1620), Max 30fps
Sub Stream: 720P (1280*720), Max 30fps
Video Bit Rate128 Kbps ~ 16 Mbps
U-codeSupport
ROISupport
Video StreamDual Streams
OSDUp to 4 OSDs
DefogDigital Defog
White BalanceAuto, Outdoor, Fine Tune, Sodium Lamp, Locked, Auto2
Digital Noise Reduction2D/3D DNR
FlipNormal, Flip Vertical, Flip Horizontal, 180°
HLCSupport
BLCSupport
Smart IRSupport
Intelligent
Auto TrackingSupport, target filtering: human only
Smart Intrusion PreventionCross line detection, Intrusion detection (support false alarm filtering and the classification of human and vehicle)
Events
Basic DetectionMotion Detection, Tampering Alarm, Audio Detection
General FunctionWatermark, IP Address Filtering, Access Policy, ARP Protection, RTSP Authentication, User Authentication
Audio
Audio CompressionG.711U, G.711A
Audio Bitrate128 Kbps
Two-way AudioSupport
SuppressionSupport
Sampling Rate16KHZ
Storage
Edge StorageMicro SD, up to 512 GB
Network StorageANR, NAS (NFS)
PTZ
Pan Range0° ~ 345°
Pan Speed1°/s～40°/s
Tilt Range-10° ~ 100°
Tilt Speed1°/s～30°/s
Number of Presets1024
Preset Patrol16 patrols, up to 64 presets for each patrol
Patrol Stay Time120s ~ 1800s
Home PositionSupport
Network
ProtocolsTLS1.3, SSH, IGMP, RTP, RTCP, SMTP, IPv4, IPv6, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTSP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, 802.1x, SNMP, QoS, SSL/TLS
Compatible IntegrationONVIF (Profile S, Profile G, Profile T, Profile M),
API, SDK
SecurityPassword Protection, Strong Password, HTTPS Encryption, Export Operation Logs, Basic and Digest Authentication for RTSP, Digest Authentication for HTTP, TLS 1.2, WSSE and Digest Authentication for ONVIF
ClientEZStation, UNV-Link, UNV-Link Pro
Web BrowserPlug-in required live view: IE 10 and above,Chrome 45 and above,Firefox 52 and above,Edge 79 and above
Interface
Audio I/O1 Input: impedance 1kΩ; amplitude 2.5V [p-p], 1 Output: impedance 600Ω; amplitude 2.5V [p-p]
Alarm I/O1/1
Built-in MicSupport
Built-in SpeakerSupport
Network1 x RJ45 10M/100M Base-TX Ethernet
Certification
EMCCE-EMC (EN 55032: 2015+A11: 2020+A1: 2020, EN 50130-4: 2011+A1: 2014, EN 61000-3-3: 2013+A1: 2019+A2: 2021, EN IEC 61000-3-2: 2019+A1: 2021)
SafetyCE LVD (EN 62368-1: 2020+A11: 2020)
UL (UL 62368-1, 2nd Ed., Issue Date: 2014-12-01)
EnvironmentCE-ROHS (2011/65/EU;(EU)2015/863)
ProtectionIP66 (IEC 60529:1989+AMD1:1999+AMD2:2013)
General
PowerDC12V(±25%), PoE(IEEE 802.3at)
Power Consumption18W
Power InterfaceØ 5.5 mm coaxial power plug
Dimensions133 x 185 x 286 mm (Ø 5.2" x 7.3" x 11.3" ) (L x W x H)
Weight788g
Working Environment-30 °C ~ 60 °C (-22 °F ~ 140 °F), Humidity: ≤95% RH (non-condensing)
Storage Environment-40 °C ~ 70 °C (-40 °F ~ 158 °F), Humidity: ≤95% RH (non-condensing)
Surge Protection2KV
Reset ButtonSupport
Web Client Language22 Languages Traditional Chinese, English, Simplified Chinese, Polish, German, Russian, French, Korean, Dutch, Czech, Portuguese (Europe), Portuguese (Brazil), Japanese, Thai, Turkish, Spanish (Latin America), Spanish (Europe), Hungarian, Italian, Vietnamese, Arabic, Slovak
QG_64280141-271e-4231-8fbb-416ad80131bd.pdf:
