60% $161.00
Uniview - IPC3612SS-ADF40KM-I0 - UNV 2MP Network IR Fixed Dome Camera(4.0mm,Premier Protection,LightHunter,Metal,30m IR,PoE, Built-in Mic, SD)
Uniview - IPC3612SS-ADF40KM-I0 - UNV 2MP Network IR Fixed Dome Camera(4.0mm,Premier Protection,LightHunter,Metal,30m IR,PoE, Built-in Mic, SD)
Uniview - IPC3612SS-ADF40KM-I0 - UNV 2MP Network IR Fixed Dome Camera(4.0mm,Premier Protection,LightHunter,Metal,30m IR,PoE, Built-in Mic, SD)
Uniview - IPC3612SS-ADF40KM-I0 - UNV 2MP Network IR Fixed Dome Camera(4.0mm,Premier Protection,LightHunter,Metal,30m IR,PoE, Built-in Mic, SD)
Uniview - IPC3612SS-ADF40KM-I0 - UNV 2MP Network IR Fixed Dome Camera(4.0mm,Premier Protection,LightHunter,Metal,30m IR,PoE, Built-in Mic, SD)
Uniview - IPC3612SS-ADF40KM-I0 - UNV 2MP Network IR Fixed Dome Camera(4.0mm,Premier Protection,LightHunter,Metal,30m IR,PoE, Built-in Mic, SD)
Uniview

Uniview - IPC3612SS-ADF40KM-I0 - Uniview 2MP Network IR Fixed Dome Camera(4.0mm,Premier Protection,LightHunter,Metal,30m IR,PoE, Built-in Mic, SD)

Product SKU: IPC3612SS-ADF40KM-I0
Available:
Only 1000 items in stock
1000 items in stock
In stock
Pre-order
Out of stock
$108.00
$269.00
  • Description
  • Specifications
  • Downloads

UNV 2MP Network IR Fixed Dome Camera(4.0mm,Premier Protection,LightHunter,Metal,30m IR,PoE, Built-in Mic, SD)



Features:

• High quality imaging with 2MP, 1/2.8"CMOS sensor
• 2MP (1920*1080)@30/25fps; 720P (1280*720)@30/25fps
• Ultra 265, H.265, H.264, MJPEG
• Smart intrusion prevention, include cross line, intrusion, enter area, leave area detection
• Based on target classification, smart intrusion prevention significantly reduce false alarm caused by leaves, birds and lights etc., accurately focus on human and, motor vehicle and non-motor vehicle
• Intelligent People Flow Counting and Crowd Density Monitoring
• LightHunter technology ensures ultra-high image quality in low illumination environment
• 120dB true WDR technology enables clear image in strong light scene
• Support 9:16 Corridor Mode
• Built-in Mic
• Smart IR, up to 30m (98ft) IR distance
• Supports 256 G Micro SD card
• IP67 protection

Camera
Sensor1/2.8", 2.0 megapixel, progressive scan, CMOS
Minimum IlluminationColour: 0.001 lux (F1.6, AGC ON)
0 lux with IR on
Day/NightIR-cut filter with auto switch (ICR)
ShutterAuto/Manual, 1 ~ 1/100000s
Adjustment anglePan: 0° ~ 360°Tilt: 0° ~ 80°Rotate: 0° ~ 360°
WDR120dB
S/N>52dB
Lens
Lens2.8mm@F1.64.0mm@F1.6
IrisFixed
Field of View (H)106.7°87.5°
Field of View (V)57.1°46.3°
Field of View (D)115.7°92.4°
DORI
DORI DistanceLens (mm)Detect (m)Observe (m)Recognize (m)Identify (m)
2.843.417.48.74.3
4.062.124.812.46.2
Illuminator
IR RangeUp to 30m (98ft) IR range
Wavelength850nm
IR On/Off ControlAuto/Manual
Video
Video CompressionUltra 265, H.265, H.264, MJPEG
H.264 code profileBaseline profile, Main profile, High profile
Frame RateMain Stream: 2MP (1920*1080), Max 30fps; 720P (1280*720), Max 30fps;
Sub Stream: 720P (1280*720), Max 30fps; D1 (720*576), Max 30fps; 640*360, Max 30fps;
Third Stream: D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF(704*288), Max 30fps; CIF(352*288), Max 30fps;
Video Bit Rate128 Kbps~16 Mbps
U-codeSupport
OSDUp to 8 OSDs
Privacy MaskUp to 4 areas
ROIUp to 8 areas
Video StreamTriple streams
White BalanceAuto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2
Digital noise reduction2D/3D DNR
Smart IRSupport
FlipNormal/Vertical/Horizontal/180°/90°Clockwise/90°Anti-clockwise
DewarpingN/A
HLCSupport
BLCSupport
DefogDigital Defog
Intelligent
Smart intrusion preventionSupport false alarm filtering: Cross Line detection, Intrusion detection, Enter Area detection, Leave Area detection
2 Statistical AnalysisPeople counting, support people flow counting and crowd density monitoring
Events
Basic DetectionMotion detection, Ultra motion detection,Tampering alarm, Audio detection
General FunctionWatermark, IP address filtering, access policy, ARP protection, RTSP authentication, user authentication
Audio
Audio CompressionG.711U, G.711A
Two-way AudioN/A
Audio Bitrate64 Kbps
SuppressionSupport
Sampling Rate8KHZ
Storage
Edge StorageMicro SD, up to 256 GB
Network StorageANR, NAS(NFS)
Network
ProtocolsIPv4, IPv6, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS, RTMP,SSL/TLS, SSH
Compatible IntegrationONVIF (Profile S, Profile G, Profile T), API,SDK
User/HostUp to 32 users. 2 user levels: administrator and common user
SecurityPassword protection, Strong password, HTTPS encryption, Export operation logs, Basic and digest authentication for RTSP, Digest authentication for HTTP, TLS 1.2, WSSE and digest authentication for ONVIF
ClientEZStation
EZView
EZLive
Web BrowserPlug-in required live view: IE 10 and above, Chrome 45 and above, Firefox 52 and above, Edge 79 and above
Plug-in free live view: Chrome 57.0 and above, Firefox 58.0 and above, Edge 16 and above
Interface
Audio I/ON/A
Alarm I/ON/A
RS485N/A
Built-in MicSupport
Built-in SpeakerN/A
WIFIN/A
Network1 * RJ45 10M/100M Base-TX Ethernet
Video OutputN/A
Certifications
EMCCE-EMC (EN 55032: 2015+A1:2020,EN 61000-3-3: 2013+A1: 2019,EN IEC 61000-3-2: 2019+A1: 2021,EN 55035: 2017+A11:2020)
FCC (FCC CFR 47 part15 B, ANSI C63.4-2014)
SafetyCE LVD (EN 62368-1:2014+A11:2017)
CB (IEC 62368-1:2014)
UL (UL 62368-1, 2nd Ed., Issue Date: 2014-12-01)
EnvironmentCE-RoHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
ProtectionIP67 (IEC 60529:1989+AMD1:1999+AMD2:2013)
General
PowerDC 12V±25%, PoE (IEEE 802.3af)
Power consumption: Max 5.0W
Power InterfaceØ 5.5mm coaxial power plug
Dimensions (Ø x H)Φ110.5 x 94.1mm (Φ4.4” x 3.7”)
Net Weight0.42kg (0.93lb)
MaterialMetal
Operating Conditions-30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing)
Strorage Environment-30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing)
Surge Protection4KV
Reset ButtonN/A
