Digital Watchdog - DWC-B6263WTIRW - Star-Light Universal HD Series, Weatherproof Bullet ,2.1MP CMOS Sensor, P-Iris, 1920x1080 resolution, AHD,CVI,TVI,960H, 2.8-12mm Varifocal Auto Iris Lens, True Wide Dynamic Range (100dB), True Day/Night with IR Cut
Digital Watchdog - DWC-B6263WTIRW - Star-Light Universal HD Series, Weatherproof Bullet ,2.1MP CMOS Sensor, P-Iris, 1920x1080 resolution, AHD,CVI,TVI,960H, 2.8-12mm Varifocal Auto Iris Lens, True Wide Dynamic Range (100dB), True Day/Night with IR Cut
Digital Watchdog - DWC-B6263WTIRW - Star-Light Universal HD Series, Weatherproof Bullet ,2.1MP CMOS Sensor, P-Iris, 1920x1080 resolution, AHD,CVI,TVI,960H, 2.8-12mm Varifocal Auto Iris Lens, True Wide Dynamic Range (100dB), True Day/Night with IR Cut
Digital Watchdog - DWC-B6263WTIRW - Star-Light Universal HD Series, Weatherproof Bullet ,2.1MP CMOS Sensor, P-Iris, 1920x1080 resolution, AHD,CVI,TVI,960H, 2.8-12mm Varifocal Auto Iris Lens, True Wide Dynamic Range (100dB), True Day/Night with IR Cut
Digital Watchdog - DWC-B6263WTIRW - Star-Light Universal HD Series, Weatherproof Bullet ,2.1MP CMOS Sensor, P-Iris, 1920x1080 resolution, AHD,CVI,TVI,960H, 2.8-12mm Varifocal Auto Iris Lens, True Wide Dynamic Range (100dB), True Day/Night with IR Cut
Digital Watchdog - DWC-B6263WTIRW - Star-Light Universal HD Series, Weatherproof Bullet ,2.1MP CMOS Sensor, P-Iris, 1920x1080 resolution, AHD,CVI,TVI,960H, 2.8-12mm Varifocal Auto Iris Lens, True Wide Dynamic Range (100dB), True Day/Night with IR Cut
Digital Watchdog - DWC-B6263WTIRW - Star-Light Universal HD Series, Weatherproof Bullet ,2.1MP CMOS Sensor, P-Iris, 1920x1080 resolution, AHD,CVI,TVI,960H, 2.8-12mm Varifocal Auto Iris Lens, True Wide Dynamic Range (100dB), True Day/Night with IR Cut
Digital Watchdog - DWC-B6263WTIRW - Star-Light Universal HD Series, Weatherproof Bullet ,2.1MP CMOS Sensor, P-Iris, 1920x1080 resolution, AHD,CVI,TVI,960H, 2.8-12mm Varifocal Auto Iris Lens, True Wide Dynamic Range (100dB), True Day/Night with IR Cut
Digital Watchdog - DWC-B6263WTIRW - Star-Light Universal HD Series, Weatherproof Bullet ,2.1MP CMOS Sensor, P-Iris, 1920x1080 resolution, AHD,CVI,TVI,960H, 2.8-12mm Varifocal Auto Iris Lens, True Wide Dynamic Range (100dB), True Day/Night with IR Cut
Digital Watchdog - DWC-B6263WTIRW - Star-Light Universal HD Series, Weatherproof Bullet ,2.1MP CMOS Sensor, P-Iris, 1920x1080 resolution, AHD,CVI,TVI,960H, 2.8-12mm Varifocal Auto Iris Lens, True Wide Dynamic Range (100dB), True Day/Night with IR Cut
Digital Watchdog

Digital Watchdog - DWC-B6263WTIRW - Star-Light Universal HD Series, Weatherproof Bullet ,2.1MP CMOS Sensor, P-Iris, 1920x1080 resolution, AHD,CVI,TVI,960H, 2.8-12mm Varifocal Auto Iris Lens, True Wide Dynamic Range (100dB), True Day/Night with IR Cut

Product SKU: DWC-B6263WTIRW
Available:
Only 1000 items in stock
1000 items in stock
In stock
Pre-order
Out of stock
$280.80
$438.00
  • Description
  • Specifications
  • Downloads

STAR-LIGHT 2.1MP, 1080p Universal HD over Coax cameras deliver crystal-clear images and support real-time 30fps HD-Analog, HD-TVI, HD-CVI and all analog signals to 960H. STAR-LIGHT Universal HD over COAX cameras are engineered to work with our VMAX A1 Universal HD over COAX DVRs using your existing coax infrastructure for a cost-effective, high resolution surveillance solution.



Star-Light Super Low-Light Technology

Star-Light Technology provides crisp clear images in both color and B/W video in extremely low light conditions. It is an ideal solution for cameras that are installed in a low-light environment, and cannot rely on external lighting for image clarity. Coupled with a powerful IR built-in, Star-Light cameras can provide unparalleled details in total darkness.



True Wide Dynamic Range (WDR)

Cameras with True Wide Dynamic Range (WDR) technology have advanced sensors that can process a wider range of lighting, dark and bright in the same image.



Features:

  • Universal HD over Coax Technology with HD-Analog, HD-TVI, HD-CVI and all Analog to 960H Signal Support
  • STAR-LIGHT Super Low Light Technology
  • 2.1MP 1/3" Image Sensor at Real-time 30fps
  • 2.8~12mm Varifocal P-Iris Lens
  • True Wide Dynamic Range (WDR)
  • OSD Control Via Coaxial (UTC)
  • 100' Smart IR with Intelligent Camera Sync.
  • Smart DNR 3D Digital Noise Reduction
  • True Day/Night Mechanical IR Cut Filter
  • De-Fog Extreme Weather Image Compensation
  • Highlight Masking Exposure (HME)
  • Auto-Sensing 24VAC/12VDC with Line Lock
  • Easy Icon Driven OSD Menu with Built-in Joystick
  • Programmable Privacy Zones
  • Auto Gain Control (AGC)
  • Backlight Compensation (BLC)
  • Dynamic Range Compressor (DRC) Reveals Low Light Detail
  • Auto White Balance (AWB)
  • RS-485 Built-in
  • UL listed
  • NDAA compliant
  • IP66 Certified Weather and Tamper Resistant
  • 5 Year Warranty
Active Pixels1944 (H) x 1092 (V)
Frequency50Hz, 60Hz
Image sensor2.1MP/1080p 1/3" CMOS sensor
Maximum resolution2.1MP/1080p
Minimum Scene Illumination in color0.0 lux (B/W), 0.03 lux (color)
Scanning SystemProgressive scan
Signal technologyCVBS up to 960H, HD-Analog, HD-CVI, HD-TVI, Universal HD over Coax® technology
LENS
Advanced Lens FeaturesP-iris
Focal Length2.8mm ~ 12mm
Horizontal Field of View (HFOV)91° ~ 28°
IR Distance100' range Smart IR™
Lens TypeVari-focal Lens
Vertical Field of View (VFOV)47.8° ~ 18.7°
I/O
I/O Alarm in/out1 output
OPERATIONAL
3D digital noise reductionSmart DNR™ 3D Digital Noise Reduction
Auto gain controlAuto
Backlight compensation (BLC)Yes
Camera ControlPelco C, Pelco D, UTP built-in
Day and nightAuto day/night, Day (color), Night (B/W)
De-fogYes
DRCYes
Gamma0.45 ~ 0.75
Mirror/flipYes
Motion DetectionYes
Privacy Zones16 programmable privacy masks
SharpnessYes
Shutter ModeAnti-Flicker, Auto, Manual
Shutter Speed1/30 ~ 1/30000
Star-Light (sense up)Off, x2-x32
White BalanceYes
Wide Dynamic Range (WDR)True WDR 100dB
Environmental Operating Humidity10-90% (non-condensing)
Environmental Operating Temperature-4°F ~ 122°F (-20°C ~ 50°C)
Mounting Accessories (Required/Optional)Optional. Sold separately
MECHANICAL
Camera Dimensions (H X W X D)*Dimensions based on the position of the sun shield cover, 8.83" x 3.8" (224.5 x 96.7 mm)
Camera Weight1.65 lbs (0.75kg)
HousingBullet
Housing ColorWhite
IP ratingWeather Resistant (IP66)
MaterialsAluminum die-casting
ELECTRICAL
American wire gauge (AWG)Cable type #18
Power ConsumptionAC24V (LED on): 4.3W, 179.1mA, AC24V (no LED): 2.7W, 112.5mA, DC12V (LED on): 4.44W, 370mA, DC12V (no LED): 3.0W, 250mA
Power Requirements12V DC, 24 V AC
GENERAL
Warranty5 Year Warranty
DWC-B6263WTIRW_20-_20datasheet.pdf:
DW_AE_DWC-B6263WTIR_W_Rev0922_0.doc:
DW_QSG_DWC-B6263WTIRW_Rev1222_0_c90918be-b18c-4de8-a544-e503241b2d24.pdf:
